Mipro MA-101U 30W portable PA system with built-in UHF radio microphone and soft carry case

Contact us for price

The Mipro MA-101U is a quality 30 watt wireless portable PA system with a high-sensitivity, full-range loudspeaker with integrated fixed frequency UHF receiver.

This item is now discontinued and has been replaced by the MA-101G that can be found here.

Free shipping on all orders £150 and over

01686 628012

General Description

The Mipro MA-101U is a quality 30 watt wireless portable PA system with a high-sensitivity, full-range loudspeaker with integrated fixed frequency UHF receiver. The system is available with either a radio handheld, lapel, or headband microphone. It has been designed for indoor or outdoor use in smaller groups (up to 200 people) at schools, places of worship, seminars, tour guides, and in leisure centres for aerobic classes and other sporting occasions.

This portable unit can be hand held, used on the shoulder strap (included) or mounted on a tripod floor stand. The built-in rechargeable battery supply allows several hours of continuous operation from only a few hours recharging time making it ideal for outdoor events. The unit also has inputs for an mp3/CD player or any other dynamic wired microphone.

Features

Powerful 30W rms (40W max) for loud, clear sound projection
Full-range high efficiency 5" loudspeaker
Lightweight contoured design-Just 2.9kg
2 power modes: AC and rechargeable battery
Up to 8 hours of operating time per charge
For crowds up to 200
Built-in diversity receiver with 1 fixed-frequency
Up to 100m operating range
A single wireless mic can broadcast to multiple MA-101 (same frequency) for expanded coverage
Line-input accepts an external iPod, MP3 or CD player
Line-output for external audio recordings
Microphone input for one wired dynamic microphone
Up to 2 mics can be used simultaneously (1 wireless & 1 wired)
Separate wireless and wired mic volume controls
Low-battery warning indicator
Built-in storage compartment
Integrated microphone stand mount
Rechargeable battery, shoulder-carrying strap included

Delivery Includes

1 MA-101U lightweight portable PA system
1 MH-801A cardiod condenser handheld microphone transmitter
 or
1 MT-801A bodypack transmitter with either
     1 MU-53L Uni-directional lapel microphone
     or
     1 MU-53HN Uni-directional headband microphone
1 SC-10 soft carry case with shoulder strap

Technical Data

Mipro MA-101U portable PA system
Receiver Channels: 1 built-in UHF channel
AF Power Output: 30W (rms) / 4Ω, 40W (MAX) / 4Ω
T.H.D.: <0.1%
Frequency Response: 60Hz~15KHz
Speaker: 5-inch, full-range
Audio Inputs: Mic-in & Line-in jacks
Power Supply: Built-in 12V/2.9AH rechargeable battery, charger & 100~240V AC switching power supply
Charging & Operating Time: 6-8 hours continuous use per 4 hours charge (automatic charging management)
Dimensions: 160mm ×178mm ×285mm
Weight: 3.1kg
Exterior Colour: Black

Mipro MH-801A Handheld Transmitter
Oscillation Mode: PLL Synthesized (Fixed)
Deregulated frequencies:
Channel A: 863.3MHz
Channel B: 863.9MHz
Channel C: 864.8MHz
Spurious Emissions: <-55dBc
Max. Deviation Range: ±68KHz
Maximum Input Level: 140dB SPL
Battery: AA  2
Dimensions: 50mm × 235mm
Weight: 210g

Mipro MT-801A Bodypack Transmitter
Oscillation Mode: PLL Synthesized (Fixed)
Deregulated frequencies:
Channel A: 863.3MHz
Channel B: 863.9MHz
Channel C: 864.8MHz
Spurious Emissions: <-55dBc
Max. Deviation Range: ±68KHz
Maximum Input Level: 0dBV
Battery: AA × 2
Dimensions: 63mm x 105mm x 21mm
Weight: 90g

Mipro MU-53L Lapel microphone
Capsule Module: 10mm premium uni-directional miniature condenser microphone
Frequency Response: 50Hz~18KHz±3dB
Capsule Impedance: 200Ω
Sensitivity: -46dBV±3dBV/Pa (0dB=1V/Pa)
Maximum SPL: 142dB (Typical, 1%THD)
Capsule-shaft holder: Dual - left and right side
Plug: MIPRO's mini-XLR
Cable Length: 150cm
Colour: Black
Weight: 19g

Mipro MU-53HN Headband microphone
Capsule Module: 10mm uni-directional miniature condenser microphone
Frequency Response: 50Hz~18KHz±3dB
Capsule Impedance: 200Ω
Sensitivity: -46dBV±3dBV/Pa (0dB=1V/Pa)
Maximum SPL: 125dB (Typical, 1%THD)
Capsule-shaft holder: Dual - left and right side
Plug: MIPRO's mini-XLR
Cable Length: 150cm
Colour: Black
Weight: 30g

More Information
ManufacturerMipro
