Mipro MA-708PA 190W portable PA system

General Description

The Mipro MA-708PA is a 190 watt portable PA system that can be configured to suit your needs. The robust one-piece system is designed for indoor or outdoor use for crowds up to 1,000 people.

The MA-708PA is a powerful two-way system that provides natural speech reinforcement and excellent music reproduction. Despite its state of the art facilities it has been designed to be user friendly and can easily be operated by non-technical members of staff. The retractable handle and built-in wheels also make the unit easily transportable

Ideal for schools, fetes, places of worship, conferences, crowd control, sporting events and many other applications.

Features

Lightweight Class-D amplifier produces 190-watt audio output
1 " titanium compression driver & 8 " woofer
Licence-free digital wireless operation
Master volume with “Memory” and “Standard” mode options - “Memory” mode saves and recalls last volume level during next power on. “Standard” mode resets to zero level
Built-in Bluetooth music player for wireless audio streaming
Retractable handle and sturdy wheels for easy transport
Built-in storage compartment for 2 Handheld transmitters
A voice priority feature that mutes the music when a wireless microphone is used
Built-in AC switching power supply for universal usage and fast battery charge
Smart 4-segment battery meter for accurate battery and charging status
3 power modes: AC, rechargeable battery and DC jack
Suitable for tripod, floor or desk mount use
Optional built-in 2.4GHz true diversity receiver modules with 10 auto-scannable frequencies
Configurable to suit your needs

Delivery Includes

1 MA-708PA portable PA system
Additional optional components if selected

Technical Data

Mipro MA-708PA
Max. Power Output: 190 Watts
Amplifier: Class D
Sensitivity: Typical: 89 dB, Maximum: 108 dB
T.H.D.: < 1%
Frequency Response: 50 Hz~18 kHz
Speaker: Tweeter: 1 " Compression Driver, Bass: 8 " Woofer
Coverage: H 80° × V 60°
Audio Inputs: Wired: XLR × 1 & 6.3 mm (1/4 ") × 1
Line-In: Unbalanced RCA jack
Audio Output: Unbalanced Line RCA jack
Bluetooth Connectivity: Yes
Extension Speaker: 6.3 mm (1/4 ") Phone jack
Master Volume Control: Manually
Controls: Tone, Voice priority & Echo on wireless mics
Storage: 2 handheld transmitters
Installation: Speaker stand, flat surface or retractable handle & wheels
Power Supply: AC: Built-in 100~240V AC switching power supply (Max. Power Consumption: 220W)
DC & Battery: 24~32V DC, 12V/4.5AH rechargeable gel cell battery (MB-70×2)
Charge Time: Up to 8 hours (automatic charging management)
Standby Time: Up to 7 hours
Battery Indicator: 4-level indicator (25/50/75/100%)
Dimensions (W x H x D): 336 × 545 × 325 mm
Weight (battery included): Approximately 16.3 kg (not including options)
Mipro CDM-2 CD/USB Player
Play format: CD and USB (2.0) flash disk.
Play feature: Selection, Search, Random and Repeat.
Wireless remote supplied: Yes
Wireless system
Receiver Channel: Up to four
Frequency Range: 2,400 ~ 2,483.5 MHz
Bandwidth: 83.5 MHz
Preset Channel: 10
Channel Set-up: Scan & ACT sync
Antenna: Built-in
Mipro ACT-24HC Handheld microphone transmitter
Frequency Range: 2.4 - 2.4835 GHz
Channel Set-Up: ACT Sync
RF Output Power: 2 mW / 10 mW switchable (country dependent)
Transmitting Mode: Frequency hopping
Max. Audio Input: 6.5 dBV
Battery Meter: 4-level green / red LED display
Battery Type: ICR 18500 rechargeable lithium battery × 1
Current Consumption: Approx. 138 mA
Operating Time: A 25-minute fast charge provides up to 1 hour operation. Minimum 10 hours of operation per 4-hour full charge (depending on the battery quality).
Dimensions: (Ø × L) 51× 248mm
Net Weight: Approx. 255 g
Mipro ACT-24TC Bodypack transmitter
Frequency Range: 2.4 - 2.4835 GHz
Channel Set-Up: ACT Sync
RF Output Power: 2 mW / 10 mW switchable (country dependent)
Transmitting Mode: Frequency hopping
Max. Audio Input: 6.5 dBV
Impedance: 1.0M Ω
Battery Meter: 4-level green / red LED display
Battery Type: 1 ICR-18500 rechargeable lithium battery
Current Consumption: Approx. 138 mA
Operating Time: A 25-minute fast charge provides up to 1 hour operation. Minimum 10 hours of operation per 4-hour full charge (depending on the battery quality).
Dimensions (W × H × D): 63 × 70 × 25mm
Net Weight: Approx. 66 g
Mipro MU-53L Lapel microphone
Capsule: Ø 10 mm uni-directional cardioid condenser microphone
Frequency Response: 50 Hz – 18 kHz
Sensitivity: -46 dBV / Pa
Max. SPL: 142 dB (typical, 1%T.H.D.)
Microphone clip: Reversible
Plug: 4-pin mini XLR
Colour    : Black
Cable Length    : 150 cm
Weight: Approx. 19 g
Mipro MU-53HN Headband microphone
Capsule: Ø 10 mm uni-directional cardioid condenser microphone
Frequency Response: 50 Hz – 18 kHz ± 3 dB
Capsule Impedance    : 200 Ω
Sensitivity: -46 dBV ± 3 dBV / Pa (0 dB = 1 V / Pa)
Maximum SPL: 125dB (typical, 1%T.H.D.)
Capsule-shaft holder: Dual - left and right side
Plug: 4-pin mini-XLR plug or TA4F
Colour: Black
Cable Length: 150 cm
Weight: 30 g
