Ampetronic ILD100 audio induction loop amplifier

The Ampetronic ILD100 audio induction loop amplifier is in a class of its own. This compact and stylish unit is capable of driving loop areas in excess of 100m² with an unrivalled clarity of sound for superior intelligibility. Based on proven and highly reliable technology it is backed by a full 5 year warranty. All connections are plug and socket style for simple quick installation. Configuration VOX switching sets priorities for each input

Twin phono (RCA) inputs provide a simple interface to hi-fi systems and televisions. Freestanding or wall mounted, the ILD100 is the obvious choice for smaller installations such as video conference rooms, private homes, TV rooms, nursing homes, receptions and waiting rooms

Features
Area coverage to >200m²
Low lifetime cost
Excellent proven reliability
5 year warranty
Unrivalled intelligibility
VOX switching – configured to prioritise Mic 1 input
Built in tone control
Very compact – 216 x 124 x 44mm
2 microphone inputs (electret)
1 line input – twin phono (RCA) connectors for TV / hi-fi connection

Delivery Includes
1 ILD100
1 Installation & Commissioning Handbook
1 Power Cable

Technical Data
AC Power Supply:
2-pole IEC320 “Fig-8” connector
20W nominal
45-65Hz

230V Version
Nominal: 230V AC
Fuse: T 100mA L
Range: 207-253V AC
Quiescent current: 48mA
Typical current: 85mA
(O/P 1.6A rms pink noise)

MICROPHONE Input:
2 x 3.5mm mono inputs
Input Impedance: 8kW
Sensitivity: -60dBu (775uVrms) for full output
Overload: >-12dBu (200mVrms)

LINE Input:
Twin RCA (phono) inputs
Input Impedance: 20kW between each input 60kW single input
Sensitivity: -30dBu (24mVrms)
for full output
Overload: >+10dBu (2.45Vrms)

Compression (AGC):
>36dB dynamic range
Controlled by adjusting input level

Output:
Current: >4.8A pk (3.4Arms) into 0.8W
Voltage: >4.2V pk (3.0Vrms)
Loop Resistance: 0.2W to 0.8W resistive or 1.0 W max impedance reactive at 1.6kHz
THD+N <0.5% @ 1kHz @ 4.8A pk

Frequency Response:
Measured at low level with no metal loss correction
80Hz to 6.5kHz -3.0dB

Environmental:
Ambient temperature: 0°C to +35°C
Relative Humidity: < 90%
IP rating: IP20

Physical:
Weight: 1.3kg
Width: 124mm
Depth: 216mm
Height: 44mm

Standards:
Meets relevant CE, EMC and safety standards
