JTS RU-8011DB/RU-G3TH radio handheld microphone system

General Description

The JTS RU-8011DB/RU-G3TH radio handheld microphone system comprises an RU-8011DB UHF PLL single channel diversity receiver and RU-G3TH handheld microphone. This system features adjustable RF output, an interchangeable capsule design on the handheld transmitter, and large LCD displays screen showing low battery and mute alerts.

This system is available in two frequency ranges-

823-865MHz includes in channel 70 and can be operated licence-free anywhere within Europe.

606.5-642MHz includes channel 38 which is the most reliable solution for portable wireless microphone systems. (Please Note. Channel 38 use requires a licence. For more information please contact us or visit Ofcom).

Features

REMOSET U synchronisation
Pilot tone and noise mute
Frequency scan
RF adjust on transmitter
Gain adjust on transmitter
Auto power off
Key lock

Delivery Includes

1 JTS RU-8011DB diversity receiver
1 JTS RU-G3TH handheld microphone

Technical Data

RU-8011DB diversity receiver
Frequency Preparation: PLL Synthesized Control
Carrier Frequency Range: 823-865MHz / 606.5-642MHz
Frequency Setting: REMOSET U
Receiving Mode: Antenna Diversity
Bandwidth: 36MHz
S/N Ratio: >105dB(A)
T.H.D: <0.6%@1KHz
Sensitivity: -95dBm,S/N>80dB
Rejection Ratio: >80 dB
Frequency Response: 50Hz~16KHz±2dB
Antenna Type: BNC Socket
Antenna Booster Power: DC12~15V/100mA
Display: LCD
Display Contents: Group, Channel, Frequency, Battery Level, Antenna A/B, Mute Display, AF Meter, RF Meter, Frequency Scan, Audio Level, Volume
Controls: Power ON/OFF, Group, Channel, Frequency, Mute Display, Key Lock, Volume, Output Attenuation (XLR), Frequency Scan(ON/OFF)
Audio Output Level: Ref/ ±22.5KHz Dev@1KHz Tone ψ6.3 Phone Jack/ -10dBV XLR Jack/ -4dBV(Line) ˴ -24dBV(MIC)
Audio Output Impedance: 600Ω
Squelch: Pilot Tone & Noise Mute
Output Connector: 1 independent balanced XLR and one Ø6.3mm unbalanced.
Power Supply: DC12~15V/300mA
Dimensions (WxHxD): 212.3 x 38.3 x 144mm
RU-G3TH handheld microphone
Frequency Preparation: PLL Synthesized Control
Carrier Frequency Range: 823-865MHz / 606.5-642MHz
Frequency Setting: REMOSET U
RF Output: Low / High
Stability: <±10KHz@Fc
Frequency Deviation: ±48KHz
Spurious Emissions: <-50dBc
Function: Power ON/OFF, Mute ON/OFF, Group, Channel, Frequency, GAIN Adjust, Auto Power Off Adjust, Lock-on Mode
Display: LCD+LED
Battery UM3: AA x2
Dimensions: 50(W) x 253(H) x 35.5(D)
