JTS RU-901G3/RU-G3TB radio bodypack system with lapel microphone (channel 38)

General Description

The JTS RU-901G3+RU-G3TB+CM-501 is a radio bodypack system with lapel microphone comprising a RU-901G3 single channel diversity receiver, an RU-G3TB bodypack transmitter and CM-501 uni-directional condenser lapel microphone. The system features REMOSET allowing automatic remote-control frequency settings of the transmitter from the receiver.

This system transmits in channel 38 which is the most reliable solution for portable wireless microphone systems. (Please Note. Channel 38 use requires a licence. For more information please contact us or visit (https://www.ofcom.org.uk/manage-your-licence/radiocommunication-licences/pmse).

Features

Phase-locked Loop (PLL) synthesized tuner
Powered by 2 x AA batteries with 12 hrs. average battery life
Equipped with 4 Pin Mini XLR connector
LCD display with channel and battery life indicator, ID number
The “lock-on” function prevents tampering and RF interruption
Extended dynamic range and smooth frequency response
Uni-directional lapel microphone

Delivery Includes

1 RU-901G3 diversity receiver
1 RU-GTB bodypack transmitter
1 CM-501 uni-directional lapel microphone

Technical Data

RU-901G3 diversity receiver

Frequency Preparation: PLL Synthesized Control
Carrier Frequency Range: UHF 606.5 - 642 MHz
Frequency Setting: Remoset U Ultrasonic
Receiving Mode:True Diversity
S/N Ratio :> 105dB
T.H.D: <0.6% @ 1KHz
Sensitivity: -95dBm, S/N>80dB
CMRR: >80 dB
Audio Frequency Response: 50Hz~18KHz±2dB
Antenna: BNC (F)
Antenna Booster Power:DC12~15V/100mA
Display: LCD
Display Contents: Group, Channel, Frequency,
Battery Status, Antenna A/B,
AF Meter(LED BAR), RF Meter (LED BAR)
Controls: Power ON/OFF, Group, Channel,
Frequency, Audio Level, Lock-on,
Volume, Output Pad, Frequency Scan (ON/OFF)
Audio Output Level: Ref:±22.5KHz Dev@1KHz Toneψ6.3
Phone Jack:-10dBV XLR Jack:-4dBV(Line)、-24dBV(MIC)
AF Output Impedance: 600Ω
Squelch: Pilot Tone & Noise Mute
Output Connector: Balanced XLR Socket x1
Unbalanced φ6.3mm PHONE JACK x1
Power Supply: DC12~15V/500mA
Dimension (m / m): 212.3mm(W)*38.3mm(H)* 144mm(D)
Notes: Actual product specifications may vary depending on region.

RU-G3TB bodypack transmitter

Frequency Preparation: PLL Synthesized Control
Carrier Frequency Range: UHF 606.5-638 MHz
Frequency Setting: Remoset U Ultrasonic
RF Outputs: Low/High
Stability: <±10KHz@ Fc
Frequency Deviation: ±48KHz
Spurious Emissions: <-50dBc
Display: LCD+LED
Input Connector : MINI XLR
Controls : Power ON/OFF, Mute ON/OFF, Group,
Channel, Frequency, GAIN Adjust,
Auto Power Off Adjust, Lock-on Mode
Battery: UM3, AA x2
Slot-in Charging: Yes
Dimensions: 62(W) x 80.3(H) x 22.6(D)

CM-501 lapel microphone

Connector type: 4-Pin Mini XLR
Frequency Response: 100~15,000 Hz
Polar Pattern: Cardioid
Sensitivity (at 1 KHz): -60±3 dB* (1mV)*0dB=1V/μbar
Impedance: 2.2kΩ
Max. SPL for 1% THD: 130dB
Dimensions: Ø10.1mm x 26.4mm
Weight: 21.5g
