JTS SIEM-111T in-ear monitoring transmitter (channel 38)

General Description

The JTS SIEM-111T is an in-ear monitoring transmitter for use with the JTS SIEM-111R in-ear monitoring receiver. It features stereo or mono transmission, an all metal case design, and large informative LCD screen.

This system operates in channel 38 which is the most reliable solution for portable wireless microphone systems. (Please Note. Channel 38 use requires a licence. For more information please contact us or visit (www.ofcom.org.uk).

Features

MPX stereo transmission, switchable to Mono
All metal case design

Delivery Includes

1 JTS SIEM-111T transmitter

Technical Data

Carrier Frequency Range: 606-642 MHz
RF Output Power: 10 mW
Nominal Frequency Deviation (modulation): ±40KHz
Audio Input Impedance: 20kΩ
Nominal Input Level: -10 dBV ; 0 dBV (ATT-10 dBV)
Maximal Input Level: 10 dBV ; 20 dBV (ATT-10 dBV)
LCD Display: AF Level, Stereo/Mono, Attenuation Level, Group, Channel, Frequency
Audio Input Connector: 2 x Balanced XLR /Ø6.3mm phone Combo Socket
Audio Output Connector: 1 x 3.5mm Stereo Phone Jack, 1 x 6.35mm Stereo Phone Jack
Loop Out Connector: 2 x Balanced Loop Out Socket
Switching Power Supply: 100-240V switching power supply
