JTS SIEM-2T SIEM-2R IE-1 in-ear monitoring system

General Description

The JTS SIEM-2 is an affordable in ear monitor system. No longer do musicians on a tight budget have to rely on foldback stage wedges!
The JTS SIEM-2 comprises of a SIEM-2T transmitter, a SIEM-2R receiver and IE-1 earphones. This in-ear monitoring system for live musicians and performers can also be used for other sound monitoring applications.

The JTS SIEM-2R is a UHF PLL mono in-ear monitor receiver with an LED display showing channel number. The also receiver includes a connection for (optional) ambient microphone with mix control-no longer do you need to remove an ear piece to hear what is happening on the stage!

This system is available in two frequency ranges-

863-865MHz operates in channel 70 and can be operated licence-free anywhere within Europe.

606.5-630MHz includes channel 38 which is the most reliable solution for portable wireless microphone systems. (Please Note. Channel 38 use requires a licence. For more information please contact us or visit Ofcom).

Features

Ambient microphone socket on receiver
60 metres of operation distance
Excellent signal to noise ratio
Lightweight ergonomic design
Selection of silicon sleeves provide best fit and sound isolation
Exceptional value for money
Hearing protection limiter

Delivery Includes

1 SIEM-2T transmitter
1 SIEM-2R receiver
1 IE-1 earphones

Technical Data

SIEM-2T transmitter
Carrier Frequency Range 863-865 MHz or 606.5-630MHz
RF Output Power 10 mW
Nominal Frequency Deviation (modulation) ±40KHz
Audio Input Impedance 20kΩ
Nominal Input Level    -20 dBV
Maximal Input Level    0 dBV
LED Display    AF Level, Channel
Audio Input Connector 2 x Balanced XLR
Loop Out Connector 2 x Ø6.3mm Balanced Loop Out Socket
Operation Voltage 12-18 VDC, 600 mA
SIEM-2R receiver
Frequency Preparation PLL Synthesized Control
Carrier Frequency Range 863-865 MHz or 606.5-630MHz
LED Display    Channel
Controls Power On/Off,
Channel selection,
Volume control
Audio Frequency Response 40~18,000 Hz
Output connector 3.5mm Dummy stereo Jack
Battery life 14 hours typical
Battery 2 AA batteries
IE-1 earphones
Frequency Response 20~20,000 Hz
Transducer Type Dynamic
Impedance 16Ω
Sensitivity (at 1000Hz) 114 dB/mW
Distortion Less than 0.3%
Cord Length 148cm with Ø3.5 stereo plug
Weight 6g (cable excluded)
