Sennheiser XSW-D Pedalboard Set

Special Price £333.18 £277.65 Regular Price £394.80

The XS Wireless Digital Pedalboard Set is designed for use with a guitar. The wireless audio set comprises an XSW-D 6.3mm (1/4”) transmitter, XSW-D Pedalboard receiver, receiver power supply, extension cable 6.3mm (1/4”), belt clip and USB-A to USB-C charging cable.

Free shipping on all orders £150 and over

01686 628012

General Description

One-touch ease-of-use wireless audio set that utilises a digital transmission to seamlessly link audio sources. This elegant solution allows you to play guitar wirelessly and still use a pedalboard, all while maintaining a reliable connection.

The new Sennheiser XS Wireless Digital system is a game changer. Why be restricted by a cable when you can use a simpler, smaller and smarter solution. With a transmitter barely larger than an audio connector and licence-free operation, wireless audio has never been easier.

The XSW-D Pedalboard Set enables your guitar to be wireless. The transmitter will plug directly in to most guitars. An extension cable and belt clip are also supplied should you want to wear the transmitter. The receiver is built into the pedalboard.


• One touch ease-of-use
• 2.4 GHz digital transmission for worldwide operation
• 75m range (250ft) in optimal conditions
• Up to 5 hours battery life on a single charge
• Switch between multiple transmitters linked to one receiver
• Configure any combination of transmitters and receivers
• Mute from either transmitter or receiver
Pedalboard with built-in tuner and wireless receiver

Delivery Includes

1 XSW-D 6.3mm (1/4”) transmitter
1 XSW-D Pedalboard receiver
1 Receiver power supply
1 Extension cable 6.3mm (1/4”)
1 Belt clip
1 USB-A to USB-C charging cable

Technical Data


XSW-D INSTRUMENT TX: approx. 122 x 24 x 28 mm
XSW-D PEDALBOARD RX: approx. 130 x 82 x 51 mm
THD, total harmonic distortion: < 0.1 %
Charging time: typ. 3 h
Audio output: max. 12 dBu
Operating temperature: -10 °C to +55 °C (14 °F to 131 °F)
Signal-to-noise ratio: ≥ 106 dB
Operating time: up to 5 h
Modulation: GFSK with TDMA
Battery Specification: Li-Ion
Capacity: 850 mAh
Codecs: aptX® Live
Frequency range: 2,400 - 2,483.5MHz
Max. Input voltage: typ. 5.0 V
Transmission power: max. 10 mW
Voltage: 3.7 V
Operating relative humidity: 95 % (non-condensing)
Latency: < 4 ms
Temperature Range: 0 °C - 60 °C (32 °F - 140 °F)
Audio frequency response: 3.5 mm Jack/XLR: 80 - 18,000 Hz, 6.3 mm Jack: 10 - 18,000 Hz
